Resolution | 4K UHD (3840 x 2160) |
Brightness (ANSI lumens) | 1800 ANSI Lumens |
Contrast Ratio (FOFO) | 100,000:1 (w/ Dynamic Iris) |
Projection System | DLP |
Resolution | 4K UHD (3840 x 2160) |
Resolution Support | VGA (640 x 480) to 4K UHD (3840 x 2160) |
Brightness (ANSI lumens) | 1800 ANSI Lumens |
Contrast Ratio (FOFO) | 100,000:1 (w/ Dynamic Iris) |
Display Color | 30 Bits (1.07 billion colors) |
Native Aspect Ratio | Native 16:9 (3 aspect ratio selectable) |
Light Source | Lamp |
Light Source Wattage | 245W |
Light Source Life |
|
Throw Ratio | 1.36 ~ 2.18 (100″ @ 3 m) |
Zoom Ratio | 1.6X |
Lens | F/# 1.81~2.1, f 14.3(Wide) ~ 22.9(Tele) |
Lens Shift | Vertical: ± 60% / Horizontal: ± 23% |
Keystone Adjustment | 1D, Vertical ± 40 degrees |
Image Size | 60″ ~ 200″ / 300″ (Clear Focus / Maximum) |
Horizontal Frequency | 15K-102KHz |
Vertical Scan Rate | 23-120Hz |
Picture Mode |
|
Color Wheel Segment | 6-Segment (RGBRGB) |
Color Wheel Speed | 2D: 96Hz ; 100Hz ; 120Hz 3D: 100Hz, 120Hz |
Rec.709 Coverage | 100% |
DCI-P3 Coverage | 100% |
HDMI | x2 (HDMI 2.0b & HDCP 2.2) |
USB Type A |
|
USB Type mini B | x1 Firmware upgrade |
Audio out (3.5mm Mini Jack) | x1 |
Audio out (S/PDIF) | x1 SPDIF audio out |
LAN (RJ45) | x1 RJ-45 LAN input jack (10/100M) |
RS232 (DB-9pin) | x1 RS232 In (D-sub 9pin, male) |
DC 12V Trigger (3.5mm Jack) | x1 (3.5mm Jack) |
IR Receiver | x2 (Front/Top) |
Wired Remote in (3.5mm Mini Jack) | x1 |
HDR | Yes (HDR10, HLG) |
Motion Enhancer (MEMC) | Yes |
ISF Night/ Day | Yes |
LAN control | Yes |
CinemaMaster Video + | Yes (4K Motion Enhancer, 4K Pixel Enhancer, Color Enhancer, Flesh Tone) |
HDTV Compatibility | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p |
Power Supply | VAC 100 ~ 240 (50/60Hz) |
Typical Power Consumption | Max 405W, Normal 330W, Eco 247W |
Standby Power Consumption | 0.5W Max. at 100 ~ 240VAC |
Network Stand-by Power Consumption | <2W |
Acoustic Noise (Typ./Eco.) | 32dBA / 26dBA |
Operating Temperature | 0~40 degrees (Celcius) |
Dimensions (W x H x D)(mm) | 492 x 168 x 349 |
Net Weight (Kg/ lbs ) | 6.5kg / 14.3lbs |
